| General |
| printer type |
Color |
| functions |
Copying, faxing, printing, scanning |
| Max. paper size |
A4 |
| technology |
laser printer |
| Laser class |
Class 1 Laser Device |
| Connectivity |
USB, LAN, WLAN |
| RAM |
Internal (512 MB) |
| Control Panel |
Touchscreen |
| Display |
Yes |
| Press |
| Print speed in black and white (A4) |
31 (pages/min.) |
| Print speed in color (A4) |
31 (pages/min.) |
| work cycle |
Up to 3,000 pages |
| Duplex printing speed in black and white (A4) |
14 (pages/min.) |
| Duplex color printing speed (A4) |
14 (pages/min.) |
| Time until first printout |
Less than 15.0 seconds from standby mode |
| Mobile printing |
Yes |
| Automatic duplex printing |
Yes |
| Printer languages |
PCL6, Brother ESC-P, PDF Version 1.7, please use . instead of ,, BR-Script3 |
| Silent mode |
Yes |
| Internal documents |
PCL (66 scalable fonts), PostScript (66 scalable fonts), 12 bitmap fonts, 16 barcodes |
| Printer functions |
N-on-1 printing, poster printing, ID card printing, brochure printing, manual duplex printing, print profiles, watermark printing |
| Internal barcodes (PCL) |
Codabar, Code128 (set A, set B, set C), Code39, Code93, EAN128 (set A, set B, set C), EAN-13, FIM (US-PostNet), GS1Databar, Interleaved 2 of 5, ISBN (EAN), ISBN (UPC-E), MSI, Post Net (US-PostNet), UPC-A, UPC-E, EAN-8 |
| printer driver |
ChromeOS (Supports native ChromeOS printing), Linux (CUPS, LPD/LPRng (x86/x64 environment)), macOS (10,14,x), Windows (10, 11, 8.1, Server), Server (2008, 2008 SP2, 2012, 2012 R2, 2016, 2019, 2022), Visit support.brother.com for the full list of supported OS and to download the latest drivers and software |
| Paper management |
| Paper feed |
Multifunction tray (100 sheets), Automatic document feeder (50 sheets), Other paper trays (250 sheets) |
| Paper edition |
Face Down (150 sheets), Face Up (1 sheet (straight path)) |
| Media formats |
Standard paper tray (A4, Letter, Legal, Folio, A5, A5 (landscape), A6, Executive, Mexico Legal), duplex printing (A4), multi-purpose tray (width: 76.2 - 215.9 mm x length: 127 - 355.6 mm), ADF (automatic document feeder) (width: 105 - 215.9 mm x length: 147.3 - 355.6 mm) |
| Media types and weights |
Automatic duplex printing (plain paper, recycled paper, 60-105 g/m², colored paper and letterhead, glossy paper), standard paper tray (plain paper, recycled paper, 60-105 g/m², colored paper and letterhead), multi-purpose tray (plain paper, recycled paper, bond paper, colored paper and letterhead, glossy paper, 60-163 g/m²), ADF (automatic document feeder) (plain paper, recycled paper, 64-90 g/m²) |
| Paper sensor |
Input |
| Copy |
| Copy functions |
Multiple copy/stacking/sorting, enlargement/reduction ratio, N-to-1 copy, 2-to-1 ID card copy, receipt copy |
| FCOT in standby mode (seconds) |
Mono (16.0 seconds), Color (17.0 seconds) |
| Grayscale |
256 shades of gray |
| Copy speed in color (A4) |
31 (pages/min.) |
| Copy speed in black and white (A4) |
31 (pages/min.) |
| Network |
| Security for LAN networks |
SSL/TLS (IPPS, HTTPS, SMTP, POP3, IMAP4), 802.1x (EAP-MD5, EAP-FAST, PEAP, EAP-TLS, EAP-TTLS), SMTP-AUTH, SNMP v3, Kerberos, IPsec, APOP |
| Wireless network security |
SSL/TLS (IPPS, HTTPS, SMTP, POP3, IMAP4), 802.1x (EAP-FAST, PEAP, EAP-TLS, EAP-TTLS, LEAP), WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES), SMTP-AUTH, SNMP v3, APOP, Kerberos, IPsec |
| Wireless setup support |
Yes |
| Scan |
| Scanner type |
Dual CIS |
| resolution |
Interpolated (up to 19200 x 19200), document glass, ADF |
| Color depth |
Output (24-bit color processing), Input (48-bit color processing) |
| Scan speed in color (A4) (3) |
28 (images/min.) |
| Scan speed in black and white (A4) (3) |
28 (images/min.) |
| Duplex color scan speed (A4) (3) |
56 (images/min.) |
| Duplex scan speed in B/W (A4) (3) |
56 (images/min.) |
| Scanner functions |
Standard functions |
| Scan to |
Scan-to-USB, Email Server, Scan-to-PC, Scan-to-SMB (Network), Network, Scan-to-SharePoint, SFTP, FTP, File, Image |
| Scan profiles |
25 Preset network |
| Scanning functions |
Skip blank pages, automatic rectification, split PDF |
| Direct scan |
Yes |
| Scan driver |
Linux (SANAE), Windows (Windows 11, Windows 10, Windows 8.1, TWAIN, WIA, Windows Server 2019, 2016, 2012R2, 2012 & 2008R2), Macintosh (TWAIN, AirPrint Scanning, 10, 14,x, ICA). A complete list of supported operating systems and the latest drivers and software can be found at support.brother.com. |
| fax |
| fax |
Automatic 2-sided faxing, telephone index, PC fax sending and receiving, paperless reception, fax stamp, ECM error correction, distinguishing ring recognition (UK, DK only), cover sheet, chain dialing, broadcasting, automatic redial, automatic reduction, Internet fax (I-Fax), memory transfer, fax to server, batch transmission |
| Fleet Management Tools |
| Fleet Management Tools |
LAN/WAN Management Software (BRAdmin Professional), Unattended Installer, MSI Installer, Embedded Web Server, Mass Deployment Tool |
| software |
| Included software |
Windows software (Brother iPrint&Scan, Tungsten PaperPort), Macintosh software (Brother iPrint&Scan Desktop), Brother Utilities |
| Consumables and accessories |
| toner |
Inbox Toner (BK Toner, CMY Toner), BK Toner (3,000 pages), CMY Toner (1,800 pages) |
| drum unit |
50,000 pages (3 pages/print job) |
| Transfer unit |
Up to 150,000 pages (3 pages/print job) |
| Toner waste container |
50,000 pages |
| Optional accessories |
Paper trays (lower tray - 250 sheets), card holder (CH-1000), lower tray - 250 sheets (LT-330CL), filter holder, base cabinet |
| Scope of delivery |
| Scope of delivery |
Power cable, installation instructions, product safety information, warranty, device, consumables |
| Dimensions and weights |
| Weight including cardboard |
33.7 kg |
| Dimensions including cardboard |
663mm (W) x 542mm (D) x 654mm (H) |
| Weight without box |
27.9 kg |
| Dimensions without box |
435mm (W) x 526mm (D) x 539mm (H) |
| work cycle |
| Recommended monthly volume |
Up to 3,000 pages |
| Operating environment |
| Average electricity consumption |
Standby mode (1.6W, 70.0W, 1.4W), Off (0.03W), Printing (580.0W), Sleep mode (10.0W), Deep sleep mode (1.4W) |
| Sound power level |
Standby mode (Inaudible), Printing (<6.56 B/A), Quiet mode (<6.0 B/A) |
| sound pressure level |
Quiet mode (44.0 dB), Printing (49.0 dB), Standby mode (Inaudible) |
| TEC value |
1.9 kWh/week |
| Operating limits |
Humidity % (20 - 80%), Degrees Celsius (10°C - 32°C), Degrees Fahrenheit (50°F - 90°F) |
| Storage limit |
Degrees Celsius (0°C - 40°C), humidity (35 - 85%), degrees Fahrenheit (32°F - 104°F) |
| Warm-up phase from standby mode (sec.) |
31 |
| directory |
| directory |
Speed voting, group voting, LDAP |
| Solutions |
| Solutions |
Brother Solutions Interface (BSI) |
| Connectivity |
| Local interface |
USB 2.0 Host (USB 2.0 Host (Front)), Hi-Speed USB 2.0 |
| Wireless network interface |
2.4 GHz: IEEE 802.11b/g/n |
| LAN interface |
Gigabit Ethernet (10Base-T/100Base-TX/1000Base-T) |
| Show IP address |
Yes |
| Wireless setup support |
Yes |
| Wireless applications |
No |
| WiFi Direct |
Yes |
| Mobile and web connectivity |
Brother iPrint & Scan, Apple AirPrint, Brother Print Service Plugin, Mopria®, Brother Apps, Web Connect |
| Security features |
| Security for LAN networks |
SSL/TLS (IPPS, HTTPS, SMTP, POP3, IMAP4), 802.1x (EAP-MD5, EAP-FAST, PEAP, EAP-TLS, EAP-TTLS), SMTP-AUTH, SNMP v3, Kerberos, IPsec, APOP |
| Wireless network security |
SSL/TLS (IPPS, HTTPS, SMTP, POP3, IMAP4), 802.1x (EAP-FAST, PEAP, EAP-TLS, EAP-TTLS, LEAP), WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES), SMTP-AUTH, SNMP v3, APOP, Kerberos, IPsec |
| IP filter |
Yes |
| IPv4 |
ARP, RARP, BOOTP, DHCP, APIPA (AutoIP), WINS/NetBIOS name resolution, DNSResolver, LLMNRresponder, LPR/LPD, Custom Raw Port/Port9100, SNMPv1/v2c/v3, TFTP server, ICMP, Web Services (Print), Web Services (Scan), SNTPClient, mDNS, SMTP Client, IPP/IPPS, HTTP/HTTPS Server, TFTP client, CIFS client, TELNET server, LDAP, FTP client, IMAP4 client, POP3 client |
| IPv6 |
NDP, RA, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port / Port9100, SNMPv1/v2c/v3, TFTP server, ICMPv6, SNTP Client, Web Services (Print), Web Services (Scan), IPP/IPPS, SMTP Client, FTP Server, HTTP/HTTPS Server, TFTP client, CIFS Client, TELNET Server, LDAP, FTP Client, IMAP4, POP3 |
| Characteristics |
Firmware updates, email notification, email report, user lock 3.0, settings lock, secure key management, secure printing, cloud secure printing, Active Directory/LDAP authentication, saving print logs |
